Folding Doors

Introduction

In situations where a door installation is necessary for large opening dimensions and where additional roof loading is not an option, Entrex solution offers the ideal solution with its in-house manufactured folding doors. Our folding doors provide significant advantages in terms of operation. These doors are fully automatic but can also be operated manually in the event of a power outage. They can be installed in a variety of opening sizes. Requiring less back run, folding doors take up less space for parking, offering a clear opening and reducing the risk of accidents. Available in both single and bi-parting options, with puff insulation and other features, our folding doors come in a wide range of configurations with remarkable variations. Constructed from strong metal surfaces, these doors act as a shield against extreme weather conditions. With various safety and signaling accessories integrated into the design, our folding doors are safer, more durable, quieter, and offer easy operation.

#

features of Folding Doors

  • Double-Walled Panels: Available with various insulations, perfect for buildings where good insulation values are required.
  • Moderate Sound Insulation: Achieved with insulated panels for noise reduction.
  • Top & Bottom Track Facilities: Allows Avians folding doors to fit any type of openings.
  • Curved Track: Enables the partition to move around corners smoothly.
  • In-Built Pass Doors: Automatic folding doors can be provided with in-built pass doors for pedestrian access.
  • Vision & Ventilation Windows: A variety of windows are available to suit specific requirements for light and airflow.
  • EPDM Profiles: Fitted to all vertical edges, providing complete sealing against dust.
  • Brush Seal: Can be integrated into the bottom of the door leaf to offer additional protection against adverse weather and dust.
  • Low Maintenance Cost: The components used are durable and do not wear and tear easily, reducing maintenance costs.
  • Technical Specifications of Folding Doors

    • Product: Automatic Sliding Folding Doors
    • Door Type: Single side / Bi-parting Type Multi-Panel Door
    • Width Min./Max.: Single Leaf: 2000mm – 14000mm and Double Leaf: 4000mm – 28000mm
    • Height Min./Max.: 3000mm – 7000mm (Larger dimensions available upon request)
    • Panel Width Min./Max.: 1000mm – 1200mm
    • Opening Dimension: Horizontal
    • Mounting Location: Inside / Outside
    • Mounting Surface: On RCC / Steel

    Door Structure of Folding Doors

    Panel Profile

  • Galvanized steel panel profile with provisions for fixing polyurethane foam panel and interlocking type EPDM rubber sealing.
  • Standard surface finish: Off-white powder coating.
  • Optional: Tubular section panel with metal sheet profile for heights over 7 meters.
  • Door Panel

  • 40mm thick, CFC-free self-extinguishing polyurethane foam panel with 40 kg/m³ density.
  • Both sides have 0.5mm thick GI precoated sheets, finished with off-white powder coating.
  • Optional: Vision window and handles on both sides.
  • Door Sealing

  • Interlocking type EPDM soft rubber sealing at the panel sides to fill the gaps and ensure complete sealing in the closed position.
  • Main Sliding Track

  • High-precision double modular sliding track with built-in space for automation mechanism.
  • Fitted on steel or RCC surface with steel cleats at the top.
  • Top Rollers

  • Double-bearing zinc-plated top rollers.
  • Folding/Door Parking Track

  • Curvilinear parking track for folding movement, with folding rollers and triangular bracket assembly.
  • Bottom Guide Track

  • Prefabricated C-channeled bottom guide track for additional support.
  • Bottom Rollers

  • Heavy-duty steel bottom rollers with ball bearings fixed to the door frame for smooth operation.
